Managing Esthetic Challenges with Anterior Implants. Part 1: Midfacial Recession Defects from Etiology to Resolution

Stephen J. Chu, DMD, MSD, CDT; and Dennis P. Tarnow, DDS

Many factors must be considered when managing esthetic challenges associated with anterior implants in order to determine what procedure is best. Two challenges exist for practitioners on a daily basis: 1) remediation of existing esthetic deformities with esthetic zone implants, and 2) being more proactive in treating patients so that esthetic problems are avoided.

Currently, one of the most significant issues in dentistry is poor implant positioning in the esthetic zone, specifically, excessive facial angulation. Although prosthetic solutions can sometimes successfully “mask” a negative condition using strategies such as gingival shaded ceramics, the primary goal should be reconstitution of both the hard and soft tissues where indicated. Surgeons should know when and how to repair such a condition in addition to taking proactive steps to avoid future problems.

The three primary challenges that restorative dentists and surgical colleagues frequently encounter are midfacial recession, interdental recession, and combination defects of the aforementioned conditions. This article will focus specifically upon the etiology and treatment of midfacial recession defects.

Midfacial recession involves exposure of the roots of teeth caused by loss of periodontal attachment (bone, cementum, and connective tissues) and/or retraction of the gingival margin from the tooth crown(s) whether natural or artificial.¹ When dealing with the natural dentition, the amount of midfacial coverage of the exposed root is always dictated and defined by the height of the interproximal tissues, ie, the interdental papillae. There are several predictable surgical procedures to accomplish this goal,^2,3 with the understanding that the graft will be adherent to the root being a vital biologic structure. With dental implants, the clinical scenario is significantly different with the implant and/or abutment surface being a non-vital structure absent of blood supply, possibly non-receptive for a coronal tissue flap or free connective tissue graft. The surface may also be embedded and contaminated with bacterial endotoxins, which would prevent tissue healing.

With the natural dentition, it is not uncommon to see midfacial soft tissue recession of patients with 1) a thin periodontal phenotype, and 2) areas of root prominence. The same can be said of implants. In an article by Chen et al on implant placement,^4,5 the primary reason that recession was encountered was poor implant positioning, specifically, excessive labial placement. An additional factor was having implants that were oversized or of greater diameter.⁶ This is not uncommon especially in post-extraction socket implant placement where larger diameter implants are needed to achieve proper primary stability. The practitioner must also be careful using a tissue-level implant when a bone-level implant is indicated in order to ensure there is adequate space and flexibility for restoration.

Excessive facial contour of a custom fabricated screw-retained abutment in combination with a cement-retained crown is another cause for midfacial recession. It is common that excessive abutment contour co-exists with excessive facial implant placement, by default. Poor implant positioning creates tremendous contour problems for the restorative dentist and ultimately the definitive prosthesis, whether a custom-abutment or one-piece restoration design is fabricated. In fact, excessive facial implant placement requires flat abutment contour or even undercontour.

Biologic width, both vertical and horizontal along the implant, should also be noted and understood because it can negatively impact the definitive esthetic outcome of treatment. The horizontal component of biologic width has an equal influence on the outcome, as excessive facial placement will lead to the loss of facial bone and soft tissue.⁷ For non-platform–switched implant systems, there is a horizontal component of biologic width, roughly 1.5 mm in distance. Consequently, if an implant is placed too close to the facial plate of bone, the horizontal component of biologic width will cause the facial bone plate to resorb, and a hard and soft-tissue dehiscence defect can be the resultant effect.

Lastly, it is well known that the periodontal phenotype of the patient plays a significant role in the potential for or resistance to gingival recession. A thin phenotype is more prone to recession; conversely, a thick phenotype is more resistant to recession.^8-11

When treating midfacial recession associated with an anterior dental implant, one must consider the angulation and facial position of the implant within the dental arch. Proper spatial implant positioning makes restoration easier and potentially allows screw-retention, thereby eliminating cementation and the associated potential peri-implantitis dilemmas.

Remedial treatment is required when an anterior implant is poorly placed with a concomitant gingival dehiscence defect. These authors find that midfacial recession associated with excessive facial implant angulation associated with a healthy implant (ie, no bone loss) is more predictably treated versus implant positioning approximating or outside the confines of the labial bone plate. The latter clinical condition usually requires implant removal with ridge reconstruction. Diagnosis of such clinical conditions is predictable with current cone beam computed tomography.

A young woman presented with a midfacial recession defect of roughly 4 mm to the junction of the abutment-implant interface (Figure 1) that was also present in her smile (Figure 2). She had previously consulted several surgeons who were hesitant to treat her because of the defect and high smile line. A cosmetic dentist subsequently referred her to the authors.

Before a clinician can decide on treatment, a diagnosis must be made whether the implant is healthy or not, meaning normal bone levels around the implant. Another decision of concern was whether to retain the dental implant. It was determined that the implant was healthy, however the recession defect was due to an overcontoured custom abutment secondary to excessive facial implant angulation (Figure 3). The tendency for most surgeons when presented with such a recession defect is to think of a “root” coverage type surgical procedure. Patients with a thin or intermediate phenotype may not respond well to such a technique. It was also mentioned previously that an exposed implant abutment is absent of blood supply and may be contaminated with endotoxins that would constrain the predictability of healing with a coronal positioned connective tissue flap. One of the tactics to predictably ensure primary flap closure of the defect is to “decoronate” or bury the implant^12,13 by removing the existing implant abutment and placing a surgical cover screw (Figure 4). Consequently, the soft tissues will heal and cover the head of the implant—“nature’s connective tissue graft” or spontaneous in-situ gingival augmentation. A resin-bonded–retained bridge was used as a provisional transitional restoration (Figure 5 and Figure 6). After a 2-week period, closure of the tissue was evident but de-epithelialization was required to ensure completion (Figure 7). Three-months post-ridge healing, sounding to the implant head with a periodontal probe revealed 5 mm of coronal soft tissue thickness (Figure 8). It was then decided that a secondary ridge augmentation procedure was not necessary, only second-stage implant uncovering surgery was needed with a crestal incision biased toward the palate. The shape of the patient’s pre-existing abutment was modified creating a flat facial contour, disinfected, and replaced as a provisional abutment (Figure 9). The original crown was also used as a temporary following an acrylic reline (Figure 10). After 1-month post-implant exposure, a new acrylic provisional restoration was fabricated and used to re-shape and sculpt the soft tissues to match those of the contralateral natural tooth¹⁴ (Figure 11). The flat contour concept of the abutment restoration is followed throughout the definitive abutment (Figure 12) and crown restoration (Figure 13 and Figure 14). Figures 15 and 16 show the intraoral and smile view of this patient, respectively, receiving remedial treatment at 5-years post-surgical treatment.

In summary, when managing midfacial soft tissue recession defects, the primary steps of treatment include: 1) implant decoronation; 2) soft-tissue augmentation, if required; 3) stage 2 implant uncovering; and 4) managing the abutment contours with flat or undercontoured subgingival profiles.

Proactive treatment requires prior understanding of the potential etiology for midfacial recession defects, and subsequently avoiding them. Placing an implant more to the palatal aspect of an edentulous ridge or post-extraction socket can circumvent the potential of midfacial recession. The only risk with such placement is fenestration of the ridge or socket at the apical area due to the anatomy of the anterior maxilla.

Restorative platform-switching can also serve as one method and treatment strategy to potentially evade midfacial recession. The reason for this effect is that platform-switched implants have half (0.6 mm to 0.7 mm) the horizontal effect of biologic width^15-17 because the restorative platform interface is moved inward or medial toward the restorative connection. Therefore, a platform-switched implant inadvertently placed too far to the facial aspect of a ridge or post-extraction socket may not cause a dehiscence defect since the horizontal influence of biologic width is only half that of a non-platform–switched implant.

The authors emphasize that surgeons should be familiar with a classification of different socket types¹⁸ in order to prevent midfacial recession with immediate implant placement. This classification was created to identify potential esthetic risks associated with post-extraction socket implants in the esthetic zone. There are three types of sockets. In type 1 sockets, the facial soft tissue and bone are both present. In type 2 sockets, the tissue may appear normal and may look like a type 1 socket from the outside, but part of the buccal plate is absent. This is the most deceptive type of socket to treat as it can fool the surgeon into believing that the socket is intact because the soft tissue level appears normal. In type 3 sockets, the soft tissues and the buccal plate of bone are both noticeably reduced because midfacial recession and attachment loss is already present. Type 3 sockets should not be difficult to identify, and the surgeon should not attempt an immediate placement. The primary goal in treatment of type 1 sockets is to preserve the buccal plate.

For type 1 sockets, the authors recommend performing an immediate implant placement in the esthetic zone. This should not be performed in types 2 and 3 sockets as midfacial recession is a risk factor in such case types. For types 2 and 3 sockets, it is recommended that the surgeon reconstruct the labial plate at a later date using a delayed protocol.

There are a few primary points to consider when placing implants into anterior post-extraction sockets; the major one being atraumatic tooth removal without flap elevation. This is because there are three sources of blood supply to the buccal plate. The periodontal ligament will be gone after the tooth is removed. The second source of blood supply is the periosteum. An issue with the periosteum is if there is flap elevation, there is a risk of impacting the blood supply. The third source of blood supply is the marrow, which is minimal-to-none in the labial bone plate of anterior extraction sockets, which are usually less than 1 mm in thickness.¹⁹

When managing esthetic challenges on anterior implants, many factors must be considered prior to treatment. One of the primary challenges facing restorative dentists and surgeons alike is midfacial recession. Using prior experience and evidence-based studies, these authors have reviewed their preferred methods for treating this condition. In addition, the authors emphasize the importance of being proactive during treatment periods in order to prevent later problems that patients might encounter. By employing these methods, patient issues can be resolved more quickly and have lasting impact.

Stephen J. Chu, DMD, MSD, CDT
Clinical Associate Professor, Director of Esthetic Education, Columbia University College of Dental Medicine, New York, New York

Dennis P. Tarnow, DDS
Clinical Professor, Director of Implant Education, Columbia University College of Dental Medicine, New York, New York

Figures and Images

Figure 1

Figure 2

Figure 3

Figure 4

Figure 5

Figure 6

Figure 7

Figure 8

Figure 9

Figure 10

Figure 11

Figure 12

Figure 13

Figure 14

Figure 15

Figure 16

Figure 1

Figure 1 Dentofacial presentation showing the midfacial soft tissue recession defect of the metal implant abutment within the patient’s smile. The patient was extremely unhappy and embarrassed about her esthetic condition.

Figure 2

Figure 2 The intraoral view shows a dehiscence defect roughly 4 mm from the free gingival margin (FGM) of the contralateral natural tooth.

Figure 3

Figure 3 The recession defect is due to an incorrectly contoured custom abutment secondary to a poorly placed implant with excessive facial angulation

Figure 4

Figure 4 The first step is removal of the implant abutment and placement of a surgical cover screw, thereby “burying” the implant; this technique is called “implant decoronation.”

Figure 5

Figure 5 The soft tissues will subsequently heal over the healthy implant allowing primary closure of the flap if subsequent augmentation is required. A resin-bonded retained provisional bridge is used as a transitional fixed restoration. A fixed provisional is more advantageous if subsequent surgery is required.

Figure 6

Figure 6 The soft tissues will subsequently heal over the healthy implant allowing primary closure of the flap if subsequent augmentation is required. A resin-bonded retained provisional bridge is used as a transitional fixed restoration. A fixed provisional is more advantageous if subsequent surgery is required.

Figure 7

Figure 7 Two-weeks post-healing in situ shows initial signs of soft tissue closure over the decoronated implant: “nature’s connective tissue graft” over the implant.

Figure 8

Figure 8 Three-months post-healing reveals 5 mm vertical soft tissue growth over the implant cover screw after sounding with a periodontal probe. An additional augmentation procedure was not required in this clinical situation.

Figure 9

Figure 9 Stage 2 surgical uncovering of the implant with a crestal incision more to the palatal aspect of the ridge allowing greater tissue thickness on the facial aspect of the abutment. The patient’s pre-existing abutment was modified with flat subgingival contours to ensure stability of the new FGM.

Figure 10

Figure 10 The patient’s pre-existing ceramometal crown was relined with acrylic resin and used as a temporary restoration.

Figure 11

Figure 11 Roughly one month after stage 2 uncovering, a new acrylic provisional crown restoration was made and used to sculpt the soft tissue shape.

Figure 12

Figure 12 An all-ceramic CAD/CAM abutment was made respecting the flat subgingival contours needed to keep the FGM margin stable in its new coronal position. Zirconia ceramics was selected for tissue color, compatibility, and strength.

Figure 13

Figure 13 Intraoral view of the inserted flat-profiled abutment showing the passive interface with the soft tissues.

Figure 14

Figure 14 The final cement-retained crown restoration on implant tooth No. 9 showing a harmonious blend and balance of periodontal health as well as white and pink color integration.

Figure 15

Figure 15 Four years post-insertion of the definitive restoration showing stability of the reconstituted soft tissue margin using the “implant decoronation” technique. Needless to say, the patient was extremely satisfied and pleased with the mid-term outcomes.

Figure 16

Figure 16 Facial view of patient showing esthetic harmony and tissue stability of remediation treatment using the “implant decoronation” technique, five years post-surgical treatment.
